型號 |
RPK-MD-20 |
RPK-MD-25 |
RPK-MD-30 |
負載 |
20kg |
25kg |
30kg |
工作半徑 |
1900mm |
1600mm |
1460mm |
卡板規(guī)格 |
1200*1200mm*100mm |
1200*1200mm*100mm |
1000*1200mm*100mm |
垂直距離 |
固定式:1700mm 升降式:2400mm |
固定式:1600mm升降式:2100mm |
固定式:1600mm升降式:2100mm |
碼垛速度 |
<8pcs/min |
<6pcs/min |
<6pcs/min |
重復(fù)位精準(zhǔn)度 |
±0.04mm |
±0.04mm |
± 0.04mm |
電源 |
單相220V/50HZ;2.5KW |
單相220V/50HZ; 3.3KW |
單相220V/50HZ;3.3KW |
